Fox Factory Race 2.0 x 10 External Bypass Remote Reservoir Shock - Class 1/2-1600 Front Right

FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.

Application: CLASS 1/2-1600, FRONT, 2.0 FRS, (5/8" SHAFT), EXBP, 4T, R/R, 10", RIGHT

• NEW proprietary Cerakote® protective ceramic coating over zinc plated basecoat
• 5/8" hard chrome plated 17-4 H900 stainless steel shaft
• Owner serviceable and rebuildable
• JM92 MIL-SPEC oil developed specifically for off-road racing
• Black Anodized CNC Machined Aluminum Components

Specifications

• Series: Factory Race
• Body Diameter (in): 2
• Body Material: Steel
• Bottom Mount: Eyelet
• Top Mount: Eyelet
• Bypass Tubes: 4
• Compressed Length (in): 17.13
• Extended Length (in): 27.19
• Mounting: 1/2 x 1-1/4
• Reservoir Dimensions: 2.17 x 8.00
• Reservoir Type: Remote
• Shaft Size (in): 5/8
• Travel (in): 10.06
• Type: External Bypass
• Eyelet Length (in): 1.68
• Valving: 807-24-070
• Seal Kit: 803-04-023
• Hose: -10 x 31.00
• Adjuster Type: External Bypass Clicker - Gen 2
• Body Finish: FOX Grey Cerakote
• Bypass Tube Size: 1/2
• Travel (rounded): 10

Installation Instructions (PDF) | Product Video
