The Gravity LED Pro6 LED light bar is an LED off road lighting system unlike any you've seen before. This Toyota Tacoma kit features patent pending Infinity Ring system, mounting brackets, hardware and a complete wiring harness.
FEATURES
-Powered by Gravity LED G6 optical inserts efficient, powerful, patented -Patent-pending Infinity Ring system enables the conversion of the Pro6 from straight to radius configurations in seconds (Patent-pending Application 14/704,736)
-Signature KC modular design is expandable to different widths
-High output, low amperage draw
-G6 LED Optics available in Spot, Driving, Wide-40 Beam Patterns
LIGHT PERFORMANCE
-Raw Lumens: 18,400 lm
-Lux @ 10 Meters: 6,700 lx
-Candela: 670,000 cd
-Beam Distance (Meters): 1,637m
SPECIFICATIONS
-Wattage: 160W
-Amp Draw: 13.04A
-Voltage: 9-32V
-Dimensions: H - 6.06" x D - 3.33" x W - 51.625"
PARTS INCLUDED
-(1) Pro6 8-Light 50" LED Light Bar
-(8) Light Covers - Black with Yellow KC Logo
-Mount Brackets and Hardware for 2005-2018 Toyota Tacoma
-Deluxe Plug-N-Play Wiring Harness with 30 amp LED Switch
PERFORMANCE Gravity LED OPTICS
Patented Gravity LED G6 optical inserts provide exceptional efficiency and light output. 20W, G6 optics are available in Spot, Driving and Wide-40 patterns.
Infinity Ring SYSTEM
The Infinity Ring system is a race-proven, adjustable linking system featuring expandable widths, modular beam shape available in a radius or straight setting between each ring.
EASY INSTALLATION ON TOYOTA TACOMA
This Pro6 LED Light Bar system comes with specifically designed Toyota Tacoma overhead roof brackets and all necessary hardware for easy mounting on OE Toyota Tacoma trucks.
RACE PROVEN STRENGTH & DURABILITY
Inspired by endurance racing, tested by KC athletes, the Pro6 shatters all performance benchmarks, while providing the most durable and scalable light bar design available today.
2005-2018 Toyota Tacoma
Fitment:
2005 Toyota Tacoma Base
2005 Toyota Tacoma Pre Runner
2005 Toyota Tacoma X-Runner
2006 Toyota Tacoma Base
2006 Toyota Tacoma Pre Runner
2006 Toyota Tacoma X-Runner
2007 Toyota Tacoma Base
2007 Toyota Tacoma Pre Runner
2007 Toyota Tacoma X-Runner
2008 Toyota Tacoma Base
2008 Toyota Tacoma Pre Runner
2008 Toyota Tacoma X-Runner
2009 Toyota Tacoma Base
2009 Toyota Tacoma Pre Runner
2009 Toyota Tacoma X-Runner
2010 Toyota Tacoma Base
2010 Toyota Tacoma Pre Runner
2010 Toyota Tacoma X-Runner
2011 Toyota Tacoma Base
2011 Toyota Tacoma Pre Runner
2011 Toyota Tacoma X-Runner
2012 Toyota Tacoma Base
2012 Toyota Tacoma Pre Runner
2012 Toyota Tacoma X-Runner
2013 Toyota Tacoma Base
2013 Toyota Tacoma Pre Runner
2013 Toyota Tacoma X-Runner
2014 Toyota Tacoma Base
2014 Toyota Tacoma Pre Runner
2015 Toyota Tacoma Base
2015 Toyota Tacoma Pre Runner
2015 Toyota Tacoma TRD Pro
2016 Toyota Tacoma Limited
2016 Toyota Tacoma SR
2016 Toyota Tacoma SR5
2016 Toyota Tacoma TRD Off-Road
2016 Toyota Tacoma TRD Sport
2017 Toyota Tacoma Limited
2017 Toyota Tacoma SR
2017 Toyota Tacoma SR5
2017 Toyota Tacoma TRD Off-Road
2017 Toyota Tacoma TRD Pro
2017 Toyota Tacoma TRD Sport
2018 Toyota Tacoma Limited
2018 Toyota Tacoma SR
2018 Toyota Tacoma SR5
2018 Toyota Tacoma TRD Off-Road
2018 Toyota Tacoma TRD Pro
2018 Toyota Tacoma TRD Sport
