DECKED DRAWER SYSTEM- RAM 1500 8 Foot (2002-2018) or RAM 1500 8 Foot Classic (2019-current)

DECKED DRAWER SYSTEM- RAM 1500 8 Foot (2002-2018) or RAM 1500 8 Foot Classic (2019-current)

Decked
SKU:
DR5
|
UPC:
851945005557
Availability:
Add to Cart and SAVE!!!
$1,499.99
(No reviews yet)
Shipping:
Free Shipping
Current Stock:

Out of stock

Out of Stock
Description

This DECKED truck bed organizer integrates with a Ram 1500 pickup truck with a bed length of 8' manufactured from 2002-2018 and/or the 2019-2021 Ram 1500 Classic body style 8' bed truck.

All DECKED Drawer Systems come with the following accessories included at no extra charge: (1) D-Box Desert Tan, (1) Crossbox Desert Tan, (1) DRAWERGANIZER™, Set of (2) Drawer Dividers. Option to add additional accessories to your drawer system after clicking add to cart, or view all accessories HERE.

NOTE: It is NOT 8' long. It takes a standard full-size DECKED system that is 75.25" long. You will have 18.5" of open space at the cabside end of your bed. A cross-over tool box or fuel transfer tank is commonly placed in this space. Read more here DECKED 8 FT BED INTEGRATION

2019-2021 RAM 1500 NOTE: Ram produced classic and new (updated) body styles for the 2019-2021 1500 pickup. This system only fits the 2019-2021 classic edition (same body style as the 2018). For more information about the 2019-2021 Ram 1500 CLICK HERE.

NOTE: Drawers are full bed-length drawers, but do not fully extend. Max drawer extension: 42” for reasons related to physics.
NOT COMPATIBLE with any in-bed towing packages including 5th Wheel and Gooseneck packages.
LINERS: Works with spray-in bed liner, but NOT a drop-in plastic bed liner.
BEDRUG: Works with BedRug mat, but NOT with a BedRug full liner.
WARRANTY: We offer a limited lifetime warranty on all DECKED products. Warranty in detail HERE.

NOTE: The system is NOT 8' long. You will have 18.5" of open space at the cabside end of your bed.

WEIGHT CAPACITIES:

2000 lb payload evenly distributed
200 lb payload per drawer

SYSTEM DIMENSIONS:

TOTAL WEIGHT: ~230 lbs
LENGTH: 75.25"
WIDTH: 63"-71"
HEIGHT: 12"
SHIPPING DIMS: 270 lbs, 78"x 39" x 23"

DRAWER DIMENSIONS:

LENGTH (top of drawer):  72.1”
LENGTH (bottom of drawer): 66.1”
WIDTH (top of drawer): 18”
WIDTH (bottom of drawer): 16.75”
HEIGHT: 8.5”
VOLUME (each): 6 FT3
EXTENSION (each): 42"



FEATURES

ITS ALL IN THE DETAILS

HIGH DENSITY POLYETHYLENE

Impervious to extreme UV light and temperatures. Born for harsh environments.

STEEL SUBFRAME

Galvanized steel skeleton in-molded to HDPE = Unmatched strength-to-weight ratio of 10:1.

FITS LIKE A GLOVE

Custom shaped to fit your bed. No loss of usable space.

AMMO CAN STORAGE

Extra compartments by the wheel-wells to maximize your storage options.

HANDLE

So easy to operate, even a bear could do it... with gloves on.

WHEELS

Urethane, sealed bearing drawer wheels. Roll. Like. Butter.

RULER & BOTTLE OPENER

Handy fine finishes because we care. Treated with robust corrosion inhibitors.

ZERO TO MINIMAL DRILLING

J-hooks attach to bed tie downs. Easy to assemble, install or remove.

RECYCLED MATERIALS

Made from 100% recycled HDPE and recycled American Steel.

DECKED truck bed storage drawers provide the ultimate access and organization for your tools and gear. Customize your truck and keep your gear organized, weatherproof and secure while maintaining full bed use. DECKED DIY tool box is durable with a 2000lb payload and 200lb per drawer rating. 100% American Made.
